MANUFACTURER LIBRARY
Official files & access
Files open on the manufacturer's website in their original language. Check the model and revision before use.
Reference documentation does not verify the identity, condition or package contents of an individual unit.
01 / MANUAL
Read the right document first
Use the quick start to prepare a channel worksheet, then consult PCLink Help for the full function and installation details. Record power grounds, sensor returns and shared functions separately.
02 / MANUAL
Installation and revision checks
The G4X XtremeX reference lists 8 ignition channels. Do not transfer the built-in wideband specification from FuryX to XtremeX.
03 / MANUAL
Keep an installation record
Save the file title and revision with your connector photographs, ECU label and wiring worksheet. Read connector viewing directions before identifying a cavity. The linked manufacturer reference describes that model; the actual unit and supplied accessories must be checked separately.
